Model: VX-h360
The VX-h360 is a compact 3-part hematology analyzer designed for efficient clinical use. It processes up to 60 samples per hour in both whole blood and pre-diluted modes, ensuring flexible operation. Equipped with a 10.4-inch color touchscreen and dual counting channels, it provides 21 hematological parameters complete with histograms and alert functions. Additional features include a built-in thermal printer, USB connectivity, and ample data storage capacity for seamless workflow.
Employing impedance and cyanide-free colorimetric methods to accurately measure WBC, RBC, PLT, and HGB. Its dual-channel counting technology enables a fast throughput of up to 60 samples per hour in clinical environments. Supporting both whole blood and pre-diluted modes with a minimal sample volume of just 9μl, the system ensures operational flexibility. The 10.4-inch color touchscreen offers intuitive control and clear visualization of results, while a robust data storage capacity of up to 500,000 records—including histograms and patient information—supports comprehensive data management. Connectivity options include four USB ports and bi-directional LIS support, facilitating seamless integration with laboratory information systems. Additionally, the built-in thermal printer and optional HP printer support provide versatile reporting solutions.
| Principle | Impedance method (WBC, RBC, PLT) and cyanide-free colorimetric method (HGB) |
|---|---|
| Sample Type | Whole blood, pre-diluted blood |
| Sample Mixing | Yes |
| Screen size | 10.4 inch color display screen with touch panel |
| Power Supply | 100–240VAC, 50/60Hz, 150VA |
| Network Connectivity | 4 USB ports, Bi-directional LIS connection, USB keyboard, mouse, printer, disk |
| Operating System | Embedded system |
| Net Weight | 24.30 KG |
| Dimension | 420(L)x295(w)x430mm(H) |
| Testing Channel | Double-channel for counting |
| Testing Speed | 60 samples/hour |
| Testing Items | 21 |
| Data Storage Capacity | 500000 |
| Data Transmission | USB, Bi-directional LIS |
| Language Interface | Multi-language |
| Printer | Built-in thermal printer, supports HP printers |
| Applicable Card Type | 3-part diluent and lyse |
